LSDA LS-3100BNC Circular Saw Machine
Carbide-tipped circular saw machine with a 3100 x 3100 mm cutting area and an 18.5 kW main saw motor.
Description
Carbide-tipped circular saw machine with a 3100 x 3100 mm cutting area and an 18.5 kW main saw motor.
Contact UMA Tools for pricing, availability and delivery.
| Product Details | |
|---|---|
| Cutting Length | 3100mm |
| Cutting Width | 3100mm |
| Maximum Cutting Height | 200mm |
| Max. Exposure Height of Saw Blade | 205mm |
| Main Saw Motor | 18.5 kW |
| Main Saw Diameter | 550mm / 630mm |
| Main Saw Shaft Core Diameter | 38mm |
| Main Saw Speed | 3000 r/min |
| Walking Motor | Servo walking 2 kW |
| Forward Speed | Maximum 9 min |
| Reverse Speed | Maximum 17 min |
| Automatic Feeding Motor | AC 1 kW / 2 unit |
- Product Specifications
| Specification | LSDA LS-3100BNC |
|---|---|
| Cutting length | 3100 mm |
| Cutting width | 3100 mm |
| Maximum cutting height | 200 mm |
| Maximum exposure height of saw blade | 205 mm |
| Main saw motor | 18.5 kW |
| Main saw diameter | 550 mm / 630 mm |
| Main saw shaft core diameter | 38 mm |
| Main saw speed | 3000 r/min |
| Servo walking | 2 kW |
| Forward speed | Maximum 9 m/min |
| Reverse speed | Maximum 17 m/min |
| Automatic feeding motor | AC 1 kW / 2 units |
